Discussion on vertical bearing capacity of soft rock socketed pile in Chongqing area
-
摘要: 结合某高层建筑软质岩嵌岩桩工程实例，对岩石单轴抗压强度试验、原位平板载荷试验、单桩静载荷试验3种方法确定的单桩竖向承载力结果进行对比分析。结果表明：平板载荷试验法确定的单桩竖向极限承载力标准值是岩石单轴抗压强度法的1.51倍，根据现行地方标准安全系数K的取值，平板载荷试验确定的单桩承载力特征值并未有所提高；单桩静载荷法得到的单桩承载力特征值是岩石单轴抗压强度法的3.12倍。根据分析结果，岩石单轴抗压强度法确定的单桩承载力偏于保守，建议考虑围压约束效应的影响；当采用岩基载荷试验法计算时，建议对重庆地方标准安全系数K的取值进行调整。Abstract: Combined with the engineering example of soft rock socketed pile in a high-rise building, the vertical bearing capacity of a single pile determined by rock uniaxial compressive strength test, in-situ plate load test, and single pile static load test was compared and analyzed. The results show that the standard value of the vertical ultimate bearing capacity of a single pile determined by the plate load test method is 1.51 times that of the rock uniaxial compressive strength method. According to the current local standard safety factor K, the characteristic value of the bearing capacity of a single pile determined by the plate load test has not been improved; The characteristic value of single pile bearing capacity obtained by the single pile static load method is 3.12 times that obtained by the rock uniaxial compressive strength method. According to the analysis results, the bearing capacity of a single pile determined by the rock uniaxial compressive strength method is conservative, and it is suggested to consider the influence of the confining pressure constraint effect. When the rock foundation load test method is used for calculation, it is suggested to adjust the value of the Chongqing local standard safety factor K.
-
表 1 三种单桩竖向承载力确定方法比较
承载力确定
方法单桩极限
承载力
标准值/kN与方法一的
比值（标准值）单桩承载力
特征值/
kN与方法一
的比值
（特征值）单轴抗压强度法
（方法一）3931 1.00 1966 1.00 岩基载荷试验法
（方法二）5946 1.51 1982 1.01 单桩静载荷试验法
（方法三）12266 3.12 6133 3.12
下载: 导出CSV
-
[1] 周成涛, 冯永能, 张 秋. 重庆市工程地质数据库建设中的几个关键问题[J]. 城市勘测, 2007, 2(4): 117-120. (ZHOU C T, FENG Y N, ZHANG Q. The key questions during the course of ChongQing engineering geology database construction[J]. Urban Geotechnical Investigation & Surveying, 2007, 2(4): 117-120. (in Chinese)ZHOU C T, FENG Y N, ZHANG Q. The key questions during the course of ChongQing engineering geology database construction[J]. Urban Geotechnical Investigation & Surveying, 2007, 2（4）: 117-120. [2] 陈小平. 重庆沙溪庙组地层岩石单轴抗压强度研究[J]. 岩土力学, 2014, 35(10): 2994-2999. (CHEN X P. Study of uniaxial compressive strength of Shaximiao formation rock in Chongqing urban area[J]. Rock and Soil Mechanics, 2014, 35(10): 2994-2999. (in Chinese)CHEN X P. Study of uniaxial compressive strength of Shaximiao formation rock in Chongqing urban area[J]. Rock and Soil Mechanics, 2014, 35（10）: 2994-2999. (in Chinese) [3] 李建军. 砂卵石土覆盖层大直径嵌岩桩及桩筏基础荷载传递机理与应用研究[D]. 太原: 太原理工大学, 2010. (LI J J. Vertical load transfer mechanism and application of large diameter rock socked pile and piled raft foundation with sand and pebble cover[D]. Taiyuan: Taiyuan University of Technology, 2010. (in Chinese)LI J J. Vertical load transfer mechanism and application of large diameter rock socked pile and piled raft foundation with sand and pebble cover[D]. Taiyuan: Taiyuan University of Technology, 2010. (in Chinese) [4] 王 焱. 结合重庆地质条件的嵌岩桩承载力和构造分析研究[D]. 重庆: 重庆交通大学, 2011. (WANG Y. The bearing capacity and structural analysis of rock-socketed piles under the geological condition in Chongqing[D]. Chongqing: Chongqing Jiaotong University, 2011. (in Chinese)WANG Y. The bearing capacity and structural analysis of rock-socketed piles under the geological condition in Chongqing[D]. Chongqing: Chongqing Jiaotong University, 2011. (in Chinese) [5] 凌 潇, 罗 康, 张莲花. 基于改进载荷试验的泥岩地基承载力研究[J]. 岩土工程技术, 2017, 31(1): 1-4,54. (LING X, LUO K, ZHANG L H. Research on bearing capacity of mudstone foundation based on the improved rock loading test[J]. Geotechnical Engineering Technique, 2017, 31(1): 1-4,54. (in Chinese) doi: 10.3969/j.issn.1007-2993.2017.01.001LING X, LUO K, ZHANG L H. Research on bearing capacity of mudstone foundation based on the improved rock loading test[J]. Geotechnical Engineering Technique, 2017, 31（1）: 1-4,54. (in Chinese) doi: 10.3969/j.issn.1007-2993.2017.01.001 [6] 刘海军, 王 新, 刘兴国, 等. 重庆地区超高层建筑软岩地基承载力取值研究[J]. 建筑结构, 2022, 52(17): 145-148. (LIU H J, WANG X, LIU X G, et al. Research on value of bearing capacity of soft rock foundation for super high-rise building in Chongqing area[J]. Building Structure, 2022, 52(17): 145-148. (in Chinese)LIU H J, WANG X, LIU X G, et al. Research on value of bearing capacity of soft rock foundation for super high-rise building in Chongqing area[J]. Building Structure, 2022, 52（17）: 145-148. (in Chinese) [7] 高文华, 朱建群, 张志敏, 等. 软质岩石地基承载力试验研究[J]. 岩石力学与工程学报, 2008, 27(5): 953-959. (GAO W H, ZHU J Q, ZHANG Z M, et al. Experiment study on bearing capacity of soft rock foundation gao[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27(5): 953-959. (in Chinese) doi: 10.3321/j.issn:1000-6915.2008.05.011GAO W H, ZHU J Q, ZHANG Z M, et al. Experiment study on bearing capacity of soft rock foundation gao[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27（5）: 953-959. (in Chinese) doi: 10.3321/j.issn:1000-6915.2008.05.011 [8] 林恺帆, 李庶林, 曹 云, 等. 岩石地基极限承载力Bell解的探讨[J]. 厦门大学学报(自然科学版), 2017, 56(5): 755-759. (LIN K F, LI S L, CAO Y, et al. Discussion about Bell solution determining ultimate bearing capacity of rock foundation[J]. Journal of Xiamen University (Natural Science), 2017, 56(5): 755-759. (in Chinese)LIN K F, LI S L, CAO Y, et al. Discussion about Bell solution determining ultimate bearing capacity of rock foundation[J]. Journal of Xiamen University (Natural Science), 2017, 56（5）: 755-759. (in Chinese) [9] 李成芳, 陈 奎, 熊启东, 等. 重庆地区软质岩地基承载力试验研究[J]. 建筑结构, 2017, 47(9): 90-93. (LI C F, CHEN K, XIONG Q D, et al. Experiment study on bearing capacity of soft rock foundation in Chongqing area[J]. Building Structure, 2017, 47(9): 90-93. (in Chinese)LI C F, CHEN K, XIONG Q D, et al. Experiment study on bearing capacity of soft rock foundation in Chongqing area[J]. Building Structure, 2017, 47（9）: 90-93. (in Chinese) [10] 刘海军, 王 新, 刘兴国. 重庆地区嵌岩桩承载力计算方法探讨[C]//第十一届深基础工程发展论坛论文集. 北京: 中国建筑工业出版社, 2021: 215-218. (LIU H J, WANG X, LIU X G. Discussion on the calculation method of rock socketed pile bearing capacity in Chongqing[C]//Proceedings of the 11th Advanced Forum of Deep Foundation. Beijing: China Architecture & Building Press, 2021: 215-218. (in Chinese)LIU H J, WANG X, LIU X G. Discussion on the calculation method of rock socketed pile bearing capacity in Chongqing[C]//Proceedings of the 11th Advanced Forum of Deep Foundation. Beijing: China Architecture & Building Press, 2021: 215-218. (in Chinese) [11] 王卫东, 吴江斌, 聂书博. 武汉绿地中心大厦大直径嵌岩桩现场试验研究[J]. 岩土工程学报, 2015, 37(11): 1945-1954. (WANG W D, WU J B, NIE S B. Field loading tests on large-diameter rock-socketed bored piles of Wuhan Greenland Center Tower[J]. Chinese Journal of Geotechnical Engineering, 2015, 37(11): 1945-1954. (in Chinese) doi: 10.11779/CJGE201511002WANG W D, WU J B, NIE S B. Field loading tests on large-diameter rock-socketed bored piles of Wuhan Greenland Center Tower[J]. Chinese Journal of Geotechnical Engineering, 2015, 37（11）: 1945-1954. (in Chinese) doi: 10.11779/CJGE201511002 [12] 孙晓娜. 公路桥梁嵌岩群桩基础竖向荷载作用下的承载特性研究[D]. 西安: 长安大学, 2013. (SUN X N. The research on the vertical load-bearing characteristics of rock-socketed pile group foundation in the highway bridges[D]. Xi’an: Chang'an University, 2013. (in Chinese)SUN X N. The research on the vertical load-bearing characteristics of rock-socketed pile group foundation in the highway bridges[D]. Xi’an: Chang'an University, 2013. (in Chinese) [13] 重庆市城乡建设委员会. 建筑桩基础设计与施工验收规范: DBJ 50—200—2014[S]. 重庆: 重庆市城乡建设委员会, 2014. (Chongqing Municipal Commission of Urban and Rural Development. Code for design and construction acceptance of building pile foundations: DBJ 50—200—2014[S]. Chongqing: Chongqing Municipal Commission of Urban and Rural Development, 2014. (in Chinese)Chongqing Municipal Commission of Urban and Rural Development. Code for design and construction acceptance of building pile foundations: DBJ 50—200—2014[S]. Chongqing: Chongqing Municipal Commission of Urban and Rural Development, 2014. (in Chinese) [14] 中华人民共和国建设部. 建筑桩基技术规范: JGJ 94—2008[S]. 北京: 中国建筑工业出版社, 2008. (Ministry of Housing and Urban-Rural Development of the People’s Republic of China. Technical code for building pile foundations: JGJ 94—2008[S]. Beijing: China Architecture & Building Press, 2008. (in Chinese)Ministry of Housing and Urban-Rural Development of the People’s Republic of China. Technical code for building pile foundations: JGJ 94—2008[S]. Beijing: China Architecture & Building Press, 2008. (in Chinese) [15] 重庆市城乡建设委员会. 建筑地基基础设计规范: DBJ 50—047—2016[S]. 重庆: 重庆市城乡建设委员会, 2016. (Chongqing Municipal Commission of Urban and Rural Development. Code for design of building foundation: DBJ 50—047—2016[S]. Chongqing: Chongqing Municipal Commission of Urban and Rural Development, 2016. (in Chinese)Chongqing Municipal Commission of Urban and Rural Development. Code for design of building foundation: DBJ 50—047—2016[S]. Chongqing: Chongqing Municipal Commission of Urban and Rural Development, 2016. (in Chinese) -
